General
Model: Premium 100 V2
Battery Capacity: 1,024Wh (20Ah)
Battery Type: LiFePO₄
Life Cycles: 4,000+ Cycles to 80% Original Capacity
Management System: MPPT Controller, BMS, etc.
Charging Temperature: 0°C to 40°C (32°F to 104°F)
Discharging Temperature: -20°C to 40°C (-4°F to 104°F)
Connectivity: WiFi & Bluetooth
UPS Switching Time: ≤10ms
Weight: 11.5 kg (25 lbs)
Dimensions (L×W×H): 320 × 215 × 250 mm (12.6 × 8.5 × 9.8 in)
Input
AC Input (Charging+Bypass): 1,800W Max.
AC Charging: 1,200W Max.
Voltage: 120VAC
Max. Current: 10A
DC Input: 1,000W Max., 12V-60V, 20A Max.
AC+DC Charging: 1,200W Max.
AC Charging Time: 45 min to 80%, 70 min to 100%
Solar Charging Time: 70 min to 100%
Charging Options: AC / PV / Car / Generator / AC+PV
Output
AC+DC Output: 2,000W Max.
AC Output: 1,800W Max.
Voltage: 120VAC
Current: 15A
Total Outlets: 11
AC Outlets: 4
DC Outlets: 7
DC Output:
• Cigarette Lighter Port 12V/10A
• 2×DC5521 Port 12V/5A per port, total 8A Max
• 2×USB-A 15W Max, 5V/3A per port
• 1×100W USB-C (5V/3A, 9V/3A, 12V/3A, 15V/3A, 20V/5A)
• 1×140W USB-C (5V/3A, 9V/3A, 15V/3A, 20V/5A, 28V/5A)
Surge Power: 3,600W
Power Lifting Mode: 2,700W
