EB3A features 430W Fast Charging that enables an 80% charge in the time it takes you to drink a cup of coffee or have a chitchat, providing sufficient power on demand.
6 Ways to Recharge
Go for an off-grid living anytime from RV camping to wilderness exploration with no fear of losing power. BLUETTI EB3A can be recharged in every way possible, either via AC, solar panels, car, generator, AC+Solar, or AC+Adapter, leaving you only peace of mind on the road.
Safety Is in Detail
Experience increased safety brought by LiFePO4 battery and BMS (Battery Management System). Compared to traditional Lithium-ion cells, the LiFePO4 battery EB3A adopts possesses a natural advantage due to its remarkable thermal and chemical stability, giving you better performance and longer life cycle (2,500 cycles to 80%). While BMS is at all times monitoring and protecting your device from every potential risk.
9 Outlets for Every Need
Flexible charging capability accommodates a wide range of charging needs. No more vying with family or friends for a quick charge. EB3A has enough ports for a simultaneous charging, classic AC and DC output, 100W Type-C, car socket, even wireless charger. Everyone will be taken good care of, regardless you're at home or staying outside.
Stay Connected with BLUETTI APP
The intuitive APP offers a truly convenient experience at your fingertips, giving you quicker access to EB3A through Bluetooth within a radius of 10m and keeping it under your control around the clock.
Tech Specs
TECHNICAL SPECIFICATIONS
BATTERY INFO
Capacity: 268.8Wh (12Ah)
Type: LiFePO4 (Lithium Iron Phosphate)
Life Cycles: 2,500+ Cycles to 80% Original Capacity
Shelf-life: Recharge to 80% Every 3-6 Months
Management System: MPPT Controller, BMS, etc.
OUTPUT
AC Outlets: 2 x 220V/5A Outlets , 600W In Total
Inverter Type: Pure Sine Wave
Surge Power: 1,200W
USB-C Port: 1 x 100W Max.
USB-A Port: 2 x 5V/3A USB-A
DC Outlets: 1 x 12V/10A (Car Outlet), 2 x 12V/10A DC 5521 (5.5mm Outlets) *All Regulated.
Wireless Charging Pad: 1 x 15W Max
INPUT
AC Charging Cable (Standard Mode): 268W Max.
AC Charging Cable (Turbo Mode): 350W Max.
Solar Input: 200W Max, VOC 12-28VDC/ 8.5A
Car Input: 12/24V from Cigarette Lighter Port
Maximum Input: 430W, with AC and Solar Input Simultaneously
RECHARGE TIMES
AC Charging Cable (Turbo Mode 350W): ≈1.3-1.8 Hours
AC Charging Cable (Standard Mode 268W): ≈1.5-2.0 Hours
Solar (200W): ≈1.8-2.0 Hours (With prime sunshine, ideal orientation and low temperature)
12V/24V Car Outlet (100W/200W): ≈3.2-3.7 or 1.9-2.4 Hours
AC + Solar (430W): ≈1.2~1.7 Hours (With prime sunshine, ideal orientation and low temperature)
Dual AC (430W): ≈1.2~1.7 Hours (With optional BLUETTTI T200 Adapter)
GENERAL
Pass-through Charging: Yes
Weight: 10.14lbs/4.6kg
Dimensions (LxWxD): 10.04*7.09*7.20in/255*180*183mm
Operating Temperature: -4-104℉ (-20-40℃)
Storage Temperature: 32-104°F (0-40°C)
Certifications: UL Standard, CEC, DOE, FCC, CA Prop 65
Warranty: 24 Months
In The Box
FAQS
FAQS
Q1: Can it charge and discharge at the same time?
A: Yes.
Q2: How do I know whether my appliance can work well with the EB3A?
A: Calculate the total wattage of your devices. EB3A would work if the load doesn't exceed its rated 600W.
Q3: How long can it run my device?
A: Running time = Battery capacity × DoD × η ÷ Device rated power
DoD refers to Depth of Discharge and η is local inverter efficiency.
For EB3A, both DoD and η are 90%. If you run a 100W LED Light with it, the running time will be: 268Wh × 90% × 90% ÷ 100W ≈ 2.17hrs
Note: 1) The formula is NOT suitable for inductive loads with compressors, like refrigerator, air conditioner, etc.
2) The above data is for reference ONLY.
Q4: What is the maximum input charging power of the EB3A?
A: 430W Max. via AC and solar charging simultaneously.
Q5: Does EB3A support BLUETTI App control?
A: Yes. Via Bluetooth.
Q6: What kind of solar panels should I choose for EB3A?
EB3A is compatible with solar panels with 12-28V Open Circuit Voltage, 200W Max. input, and MC4 connectors.
Highly Recommended:
1x BLUETTI PV120: ≈2.7hrs*.
1x BLUETTI PV200: ≈1.8hrs*.
* For reference ONLY.
Q7: Is the EB3A power station waterproof?
A. No. Please do NOT store it in a humid environment for a long time.
Q8: How to deposit EB3A?
A. Store in a dry and well-ventilated place and recharge to 80% every 3-6 months.
Q9: Can I use or charge EB3A in sub-zero temperatures?
Temperature ranges for EB3A are:
Charge: 0-40℃ (32-104℉);
Discharge: -20-40℃ (-4-104℉);
Storage: -10-45℃ (14-113°F).
Technically, it can power electrical devices in sub-zero temperatures, but please avoid charging it.
Q10: Can it be laid on its side to save space?
A. No. Because that may loose the internal structure. Please keep it upright to ensure its performance.
Q11: Is it possible to replace the built-in battery?
A. No. If the internal battery pack malfunctions, please contact BLUETTI Customer Service.
Q12: Can I expand its capacity by connecting with B230/B300 battery?
A. No.
